CTS 300

CTS 300

Compatible processes compare with traditional industry

CTS has standard format of 1-bittiff with data convert function to well provide higher process performance in printing, paper, packaging, glass and other screen printing related industry.











Digital Imaging Technology

TI imaging generator device (DMD Chip) is applied to generate digital images. DMD is composed of 800,000 13.68-micron micro-mirrors, which can be guaranteed clear and sharp square dots within the light spot range

of 13.5mm*17.2mm. CTS Technology will become the industry's new standard.







High Resolution

The optical resolution of 1270dpi makes it easy to raster 133L to achieve the high- fidelity effect of dot. The optical resolution of 2540dpi can not only represent the high resolution curve but also perfectly represent the FM dot. Raster 133L lines of four-color screen production, be able to 3% dot.







High Power Laser for EOM

High power laser series product as 10w, 15w, 20w, can achieve 100um emulsion thick +80um mesh thick exposure,

suitable for special screen plate such as carbon oil, photosensitive capillary and other screen plate

production.




specification

Model/Specification

CTS300

Scope of application

Textile printing, paper, packaging, glass etc.

Max screen size

1200mm×1300mm

Min screen size

400mm×400mm

Max exposure size

1100mmx1250mm

Thickness of frame

25-45mm (can be customized)

Line of resolution

Theoretical data: 35±5μm (PS Plate), actual data: 1 - 1.5 times of mesh width (depends on the emulsion and screen)

Imaging system technology

TI DLP technology

Thickness of emulsion

6-100 μm

Exposure time

120-240s/m2, 350 mesh yellow screen, (SBQ emulsion)

Date resolution

1270dpi/2540dpi

Raster

133L

Focus system

Real time control focus

File format

1_bit tiff etc.

Laser type

UVLD laser 405±5nm

Laser power

10W/15W/20W

Equipment size (mm)

2950x1900x1650

Equipment net weight

2800KG

Conditions

Yellow room. Clean level: 100000 level, 22±2°C, 40-70% relative humidity (No condensation)

Power

Single phase 220v, 50/60 Hz, 4KW (CTS300), gas: 1L/min
